Sand production line, building material, gypsum industry
Overview
CXFL series powder separator is usually called as powder concentrator. It is based on American technology, and is an ideal device to separate powder (≤0.075mm) from manufactured sand in the dry way. Through controlling the powder ingredient of manufactured sand easily, it can meet different clients’ requirements.
Introduction
1. Easy operation and adjustable fitness; 2. Convenient wear parts replacement and maintenance, long service life; 3. Energy saving, high efficiency and large capacity; 4. Low investment, environmental protection and convenient installation;
Technical data
Model
Capacity(t/h)
Fan Power(KW)
Motor Power(KW)
Major Axis Speed(r/min)
CXFL-2000
20-35
30
11
190-380
CXFL-3000
30-45
37
15
150-350
CXFL-3500
45-55
55
18.5
130-320
CXFL-4000
55-75
90
30
120-280
CXFL-5000
75-100
132
55
120-280
Note: Capacity is relative to physical character, feeding type,feeding size, composition, etc.
